Light Source

LED White light

Aiming Light

Green Dot

Image Sensor

1280*800 pixels (Global Shutter)

CPU

1.2G Dual core

Resolution(maximum)

3mils

Minimum Print Contrast

20% Reflection Difference

Motion Tolerance

2M/S

Image Field of View

Horizontal: 50°; Vertical: 38°

Reading Angle

Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°

Decoding Capability

1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.

2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code

Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.

Reading Indicators

LED light&Buzzer(adjustable tone and volume）

Typical depth of Field

Precision Barcode  Depth of Field

3.34mil CODE 128  40mm—80mm

5mil  CODE128  35mm—135mm

3.34mil EAN-13  40mm—80mm

5mil  EAN-13  30mm—105mm

13.34mil EAN-13  30mm—290mm

5mil  PDF417  35mm—105mm

15mil  QR     20mm—155mm

10mil  DM   30mm—140mm

20mil  QR   30mm—265mm

(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)

Electrical Parameter

Current

Working current(Standard): 80 mA ; Standby current(Standard): 130 mA

Input Voltage

5 VDC (+/- 10%)/500mA

Environmental Parameter

ESD protection(Air discharge)

8 kV

Drop resistance

Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.

Temperature

Working: -10 to 50 °C

Storage/Transport: -20 to 65 °C

Humidity(non-condensing)

5 - 95%

Ambient light

Indoor: 0 to 6,000 lux; Outdoor: 0 to 100,000 lux

Product Size

172*67*87mm

Interfaces

RS-232; USB HID; USB COM; HID POS available as per customer’s needs

Transmission

Support multi-language transmission, compatible with major operating systems, support the editing of barcode data.
